1 GS/s 采样率的高速数字化仪
主要特点
4通道模拟输入
0.16% 满量程精度
采样率:每通道1 GS/s
多通道同步采集,精度高达10 ps
可在线切换的两档增益
模拟输入带宽高达200 MHz
直流耦合,50 Ω输入阻抗
4 GB DDR4缓存
产品介绍
PXIe-9824是一款高分辨率、高速PXIe数字化仪,支持16位分辨率和1 GS/s的采样率。它采用高速、大容量数据缓冲和高速数据交换技术,适合精确捕捉高速瞬态信号。可用于构建多通道、高精度、同步采集系统。
PXIe-9824 (PN: JY8727784-01) | 4-CH, 1 GS/s, 16-bit, 2 Vpp, BW:200 MHz PXIe Digitizer
Main Features
4 channels 16-bit high-speed, high-precision analog input
0.16% full scale accuracy
1 GS/s/ch sampling rate
Multi-channel synchronized acquisition with a accuracy up to 100 ps
Two levels of gain that can be switched online
Analog Input Bandwidth up to 200 MHz
DC Coupling , 50 Ω Input Impedance
4 GB DDR4 Buffer Memory
Overview
PXIe-9824 is a high-resolution and high-speed PXIe digitizer that supports a 16-bit resolution and a 1 GS/s (Giga Samples Per Second) sampling rate. It utilizes high-speed, large-capacity data buffering and high-speed data exchange technology, making it suitable for the precise capture of high-speed, transient signals. It can be used to construct multi-channel, high-precision, synchronized acquisition systems.
